Description
The YR01828 Benchtop Conductivity / TDS / Salinity / Resistivity Meter is a sophisticated instrument designed for precision measurements in laboratories and industrial settings. Featuring a 7-inch colored capacitive touch screen with high sensitivity, this meter offers real-time data transfer via Bluetooth and supports both wireless Bluetooth printing and PC connection. It comes equipped with intelligent functions such as automatic calibration and ATC, and includes a smart electrode status display for ensuring accuracy. With the ability to store up to 1000 sets of test data that can be exported to USB and viewed in Excel, this meter combines convenience with cutting-edge technology.
Market Price
The pricing for benchtop conductivity meters like the YR01828 typically ranges from $500 to $800, reflecting its advanced technology and reliable data accuracy. For those seeking precise and consistent measurements, investing in this meter is a decision backed by numerous satisfied laboratory professionals.
Frequently Asked Questions
Can data from the YR01828 be transferred to a smartphone? Yes, real-time data transfer to a mobile phone is possible via Bluetooth.
What is the data storage capacity of this meter? The device can store up to 1000 sets of test data.
Advantages and Disadvantages
The YR01828 offers numerous advantages, including high accuracy, multiple calibration options, and an easy-to-use interface. However, the complexity of its functions may present a learning curve for new users.
Product Use in the Field
In practical applications, the YR01828 is instrumental in laboratories requiring precise measurements of conductivity, TDS, salinity, and resistivity. Its robust design ensures reliability across various environmental conditions.
Recommendations
For optimal performance, it is recommended to regularly calibrate the YR01828 and ensure it is used within its specified temperature and humidity ranges. Proper maintenance, including keeping the touch screen clean and ensuring software updates, will prolong the device’s lifespan.
Features
- 7-inch colored capacitive touch screen with high sensitivity
- Intelligent functions: Automatic calibration, ATC, data storage
- 1000 sets of data storage capacity
- Wireless Bluetooth connectivity
- Multi-point calibration support
Technical Specifications
| Model | YR01828 | |
| Cond. | Measuring range | Conductivity: |
| (0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm, (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm, | ||
| (200~2000)mS/cm (K=10) | ||
| TDS:(0 ~ 100)g/L | ||
| Salinity:(0 ~ 100)ppt | ||
| Resistivity:(0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 50)ºC, auto | |
| Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
| Reference Temp. | 25ºC,20ºC,18ºC | |
| Temp. | Range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
| Other | Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB, RS232, Bluetooth | |
| Ambient Temp. | 15 ~ 30 ºC | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 240×170×70mm/600g | |
| Shipping Size/G.W. | 470x430x85mm/2.6kg | |
