Veterinary Handheld Slit Lamp (2-Magnification) YR06199

ManufacturerKalstein

Description

The Veterinary Handheld Slit Lamp (2-Magnification) YR06199 is a state-of-the-art portable device designed for veterinary eye examinations. This lightweight slit lamp features a high-brightness LED light with a cold-light illuminator, capable of delivering up to 30,000 LUX for exceptional illumination clarity. With no need for external power, it’s completely battery-operated, allowing for 5 to 6 hours of continuous use with a full charge. Its compact design, weighing only 700 grams with the battery, makes it an ideal choice for veterinarians on the go. The adjustable slit width, telescopic forehead-rest, and revolvable objective lens ensure precise control and comfort during eye examinations. Coupled with various filters such as heat-resistant and redfree filters, this device offers versatility for different examination needs.

Market Price

In the competitive market for handheld slit lamps, the average price range for high-quality models like the Veterinary Handheld Slit Lamp YR06199 typically falls between $3200 and $3800 USD. This range offers a competitive perspective for potential buyers seeking durability, precision, and portability in one package. For those interested in acquiring this essential veterinary tool, obtaining a tailored quotation can ensure the best value for your investment.

Frequently Asked Questions

Q: How long does the battery last on a full charge?
A: The battery can power the slit lamp for 5-6 hours continuously on a full charge.

Q: Is the slit width adjustable?
A: Yes, the slit width can be adjusted continuously from 0 to 12mm for precision.

Advantages and Disadvantages

This portable slit lamp offers significant advantages including high portability, extended battery life, and versatile use with multiple filters. However, certain users might find the reliance on battery power a limitation if extended examination sessions exceed the battery’s capacity.

Product Usage in the Field

The Veterinary Handheld Slit Lamp is highly practical in various veterinary settings, particularly for those engaged in fieldwork or mobile clinics. Its portability and reliability make it an indispensable tool for comprehensive ocular examinations, enabling veterinarians to deliver quality eye care to animals in diverse environments.

Recommendations

For optimal performance, ensure the slit lamp is regularly cleaned and its battery fully charged before each use. Store the device in a protective case to prevent damage during transport. Additionally, familiarize yourself with the filter options to fully utilize the diagnostic capabilities of the slit lamp.

Features

– High-brightness LED light with 30,000 LUX.
– Slit width adjustable from 0 to 12mm.
– Compact design weighing only 700g, including battery.
– Continuous use for 5-6 hours on a single charge.
– Various filters including heat absorption and cobalt blue.

Technical Specifications

Model Item YR06199
Microscope Microscope Type Converging
Objective Lens 1.0X、1.6X
Eyepiece 10X
Total Magnifications 10X、16X
Working Distance 81mm
Intraocular Distance 45mm―78mm
Diopter Adjustment -8D―+8D
Illumination Slit Width 0―12mm Continuous
Slit Height 1-12mm
Slit Angle ф0.2mm,ф1mm,ф5mm,ф12mm
Filters Heat Absorption; Yellow; Redfree(Green); Cobalt Blue
Illumination Bulb High-Brightness White LED
Brightness ≥30000Lux
Power LED Working Voltage d. c. 3 V
Battery Li-ion Battery; 7.4V, 680mAh. Full Battery can supply 5-6 hours continuously
Weight and Dimension Dimension 169.5mm×109.5mm×228.5mm
Weight ≤4kg (Including Battery)

Additional information

Weight 5 kg
Dimensions 29 × 34 × 48 cm
