Description
Seven working modes with compact and light design
Monopolar Cut (Pure cut, Blend 1, Blend 2)
Monopolar Coag (Fulgurate Coag, Spray Coag)
Bipolar Cut, Bipolar Coag fully meet different surgery requirement.
Tissue Monitoring Technology
This technology monitors the tissue density, especially for polypectomy and papillotomy, cutting is smartly divided in cut and pause, so that coagulation occurs in each pause.The system is intelligent to change the pause interval as tissue density changes, hence produces fine cutting with coagulation effect.
Technical Specifications
| Model | YR02149 | |
| Working Mode | Max Power / Rated Load | |
|
Monopolar Cut
|
Pure cut | 120W / 500Ω |
| Blend 1 | 90W / 500Ω | |
| Blend 2 | 80W / 500Ω | |
|
Monopolar Coag
|
Fulgurate Coag | 60W / 500Ω |
| Spray Coag | 40W / 500Ω | |
| Bipolar Cut | Bipolar Cut | 60W / 100Ω |
| Bipolar Coag | Bipolar Coag | 60W / 100Ω |
|
Electrical requirement
|
Monopolar Measuring Frequency | 4.0MHZ ±2% |
| Bipolar Measuring Frequency | 1.84MHZ ±2% | |
| Max Input Currency | 1400VA | |
|
Environmental Conditions for Use
|
Condition | Range |
| Temperature | 50°C to 40°C | |
| Relative humidity | ≤ 95% non-condensing | |
| Pressure | 700 hPa to 1060 hPa | |
