Monocular Microscope with Digital Screen YR07016-M

The YR07016-M is an optical microscopy system that stands out for its dual illumination system with adjustable brightness upper and lower LEDs and a lifespan of up to 50,000 hours. It incorporates a double-layer mechanical stage with precise X/Y movement, coarse and fine coaxial focus, and the option to upgrade to a heating platform. Its versatility in power supply includes a universal AC power adapter and compatibility with a rechargeable 18650 battery for portable use. Its fully metallic body ensures great durability and resistance to continuous use in classrooms or basic research centers.

Advanced Design and Technology

• Integrated Digital LCD Screen: Displays in real-time the operating temperature, battery level, charging status, and the status of the upper and lower LEDs.

• Dual Illumination System: Features a 1 W lower LED and 0.06 W upper illumination, both with adjustable brightness and a prolonged lifespan of 50,000 hours.

• Precision Mechanical Stage: Double-layer platform of 95x105 mm with X/Y movement of 20x50 mm and coaxial coarse and fine focus controls (division of 0.008 mm).

• High-Quality Achromatic Optics: Includes a monocular head tilted at 30° and rotatable 360°, WF10x/16mm and WF16x/13mm eyepieces, and 4x, 10x, and 40x(S) objectives.

• Portability and Dual Power: Operates via a 5V1A AC/DC power adapter and supports a 2000 mAh rechargeable 18650 battery for wireless operation.

Frequently Asked Questions (FAQ)

• What does the standard packing list of the equipment include? It includes the microscope body, power adapter, power cable, 18650 battery, instruction manual, and dust cover.

• Is it possible to use the rechargeable battery on air shipments? Due to aviation safety regulations, the rechargeable 18650 battery is supplied separately or not included in purely air shipments.

• Can the microscope stage be upgraded? Yes, the mechanical platform can optionally be upgraded to a heating stage with temperature control function.

Key Advantages:

• Robust Metal Construction: Its fully metallic body offers great stability, solidity, and resistance to daily wear.

• Energy Independence: The option to use a rechargeable battery allows for fieldwork or practices where there are no accessible electrical outlets.

• Ergonomics and Control: Head tilted at 30° with 360° rotation and coaxial controls for comfortable and fatigue-free focusing.

Disadvantages / Considerations:

• Standard Objective Limitation: The base model includes objectives up to 40x(S) (with configuration options as required), primarily focused on educational and routine applications.

• Battery Transport Restrictions: Air shipping restrictions for lithium batteries may require additional logistical considerations.

Product Use in the Field and Recommendations

• Ideal Applications: Laboratory practices in educational institutions, secondary and university education, teaching biology, basic medicine, and scientific workshops.

• Recommended Maintenance: Use the provided dust cover when the equipment is not in use and clean the optical lenses only with specialized optical paper.

• Operation Recommendation: Check the battery indicator on the LCD screen before starting long work sessions without connection to the electrical network.
